ADTi 20MP 20L V1 APS-C Drone Mapping Cameras

47,343.96 Incl. GST. Claimable with B2B Billing.

Specifications:

Sensor Type: CMOS
Sensor Manufacturer: Sony
Effective Megapixels: 20
Sensor Format: APS-C
Sensor Size: 357.3 mm² (23.20 mm x 15.40 mm)
Approximate Pixel Pitch: 4.25 microns

And many more…

Guaranteed Safe Checkout

Categories: ,
Description

Buy These ADTi 20MP 20L V1 APS-C Drone Mapping Cameras Now

These ADTi 20MP 20L V1 APS-C Drone Mapping Cameras stand for the ultimate in aerial imaging technology. This ADTi Drone Mapping Camera is tailored for high-precision mapping and data collection. This product is designed to cater to professionals across various fields such as agriculture, land surveying, and infrastructure inspection. This 20MP APS-C Drone Camera ensures unparalleled image quality and dynamic range. Use this product to capture detailed agricultural plots, survey expansive land areas, or inspect intricate infrastructure; the 20L V1 Drone Camera is your reliable partner in achieving accurate and professional results.



TAKE A TOUR OF THIS CATEGORY PAGE TO EXPLORE MORE SUCH PRODUCTS.



ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Exceptional Performance And Design

This High-Resolution Drone Mapping Camera is crafted for efficiency and durability. These ADTi 20MP 20L V1 APS-C Drone Mapping Cameras combine a lightweight build with robust performance. At just 108 grams, this camera is both compact and portable, making it easy to integrate into your drone setup without adding excessive weight. This APS-C Sensor Drone Camera’s dimensions of 73 x 62 x 36 mm allow for a snug fit, ensuring minimal impact on drone flight dynamics. This careful balance between size and weight optimizes this camera's performance while minimizing the strain on your drone's battery and propulsion systems.

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Innovative Features For Optimal Operation

This Professional Drone Mapping Equipment camera boasts a range of features designed to enhance your mapping and imaging experience. One of the standout features is its activated cooling fan, which helps prevent overheating and ensures the camera operates at peak performance even during extended flight missions. This feature is crucial for maintaining image clarity and preventing any thermal degradation of your equipment. Additionally, this 20MP Drone Camera For Mapping's design provides a compromise between image size, storage, and processing requirements, allowing for efficient data management without compromising on quality.

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Cutting Edge Sensor Technology

At the heart of these ADTi 20MP 20L V1 APS-C Drone Mapping Cameras is a high-performance CMOS sensor manufactured by Sony. With an effective resolution of 20 megapixels and an APS-C sensor format, this Drone Camera For Aerial Surveying captures images with exceptional detail and clarity. The sensor's size of 357.3 mm² (23.20 mm x 15.40 mm) and approximate pixel pitch of 4.25 microns contribute to its superior image quality, offering a focal length multiplier of 1.5x and an aspect ratio of 3:2. The RGBG color filter type and fixed anti-aliasing filter ensure accurate color reproduction and minimal artifacts, while the color depth of 23.8 bits and maximum effective ISO of 1,089 allow for high-quality images in diverse lighting conditions.

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Versatile Image And Video Capture

These ADTi 20MP 20L V1 APS-C Drone Mapping Cameras excel in both image and video capture, providing a wide range of resolutions to meet your specific needs. For still images, this High-Quality Drone Imaging Camera offers resolutions up to 5456 x 3632 pixels (19.8 MP) in a 3:2 aspect ratio and various other resolutions, including 16.7 MP, 10.0 MP, and 5.0 MP. This versatility ensures you have the flexibility to choose the optimal resolution for different mapping tasks. Additionally, this camera supports multiple image file formats, including JPEG, RAW, and RAW+JPEG, giving you the freedom to select the format that best suits your workflow.

In terms of video capture, these ADTi 20MP 20L V1 APS-C Drone Mapping Cameras provide high-definition resolutions such as 1920 x 1080 at 60i or 24p and 1440 x 1080 at 30p, ensuring smooth and detailed video recording. This camera's video file formats include AVCHD 2.0 and MP4, with HD video output via HDMI, making it easy to integrate with various video recording and processing systems.

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Lens And Optics For Precision Imaging

Equipped with a Sony E lens mount, these ADTi 20MP 20L V1 APS-C Drone Mapping Cameras offer both auto and manual focus capabilities, with a normal focus range extending from 25 cm to infinity. This flexibility ensures precise focus adjustments for different imaging scenarios, enhancing the overall quality of your aerial shots. This Drone Camera With APS-C Sensor's lens and optics are designed to deliver sharp, clear images, making it suitable for detailed mapping and inspection tasks.

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: User-Friendly Display And Operating Specifications

For ease of use, these ADTi 20MP 20L V1 APS-C Drone Mapping Cameras feature a detached 5-inch display with a 5V DC power supply and intuitive button controls. This display allows for convenient camera settings adjustments and real-time monitoring of your shots. This 20MP APS-C Drone Camera itself operates within a temperature range of -10 to 40°C, ensuring reliable performance in various environmental conditions. It is powered by a 10-25V DC Lipo or Li-ion battery, providing flexibility and compatibility with different power sources.

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Features At A Glance

  • Lightweight Design: Camera body weighs only 108 g.
  • Compact Size: Measures 73 x 62 x 36 mm
  • Efficient Performance: Balances image size with storage, light, and processing needs
  • Activated Cooling Fan: Prevents overheating to maintain optimal performance

Sensor Specifications:

  • Sensor Type: CMOS
  • Sensor Manufacturer: Sony
  • Effective Megapixels: 20
  • Sensor Format: APS-C
  • Sensor Size: 357.3 mm² (23.20 mm x 15.40 mm)
  • Approximate Pixel Pitch: 4.25 microns
  • Focal Length Multiplier: 1.5x
  • Aspect Ratio: 3:2
  • Color Filter Type: RGBG
  • Anti-Aliasing Filter: Fixed
  • Color Depth: 23.8 bits
  • Maximum Effective ISO: 1,089

Image Capture Resolution:

  • 5456 x 3632: 19.8 MP (3:2)
  • 5456 x 3064: 16.7 MP (16:9)
  • 3872 x 2576: 10.0 MP (3:2)
  • 3872 x 2176: 8.4 MP (16:9)
  • 2736 x 1824: 5.0 MP (3:2)
  • 2736 x 1536: 4.2 MP (16:9)
  • 12416 x 1856: 23.0 MP (other)
  • 8192 x 1856: 15.2 MP (other)
  • 2160 x 5536: 12.0 MP (other)
  • 2160 x 3872: 8.4 MP (other)
  • Image File Formats: JPEG, RAW, RAW+JPEG
  • Continuous-mode Frames/Second: 2.0

Video Capture Resolution:

  • 1920 x 1080: 60i or 24p (24/17 Mbps)
  • 1440 x 1080: 30p (12 Mbps)
  • 640 x 480: 30p (3 Mbps)
  • Video File Formats: AVCHD 2.0 / MP4
  • HD Video Out: Yes
  • HD Video Connection: HDMI

Lens & Optics Specifications:

  • Lens Mount: Sony E
  • Normal Focus Range: 25 cm to Infinity
  • Auto Focus: Yes
  • Manual Focus: Yes

Display (Detached) Specifications:

  • Power: 5V DC
  • Buttons: Yes
  • Screen Size: 5 inches

Camera Specifications:

  • Camera Size: 73 x 62 x 36 mm
  • Camera Weight: 108 g
  • Package Size: 300 x 200 x 150 mm
  • Package Weight: 500 g
  • Power Supply: 10-25V DC Lipo or Li-ion
  • Operating Temperature: -10 to 40 °C

ADTi 20MP 20L V1 APS-C Drone Mapping Cameras: Purchase Now

These ADTi 20MP 20L V1 APS-C Drone Mapping Cameras are a sophisticated and versatile tool designed to meet the demands of professional aerial imaging and mapping. This APS-C Sensor Drone Camera’s lightweight and compact design, combined with advanced sensor technology and versatile imaging capabilities, make it an ideal choice for a range of applications. Whether you are capturing detailed agricultural data, conducting land surveys, or inspecting infrastructure, this ADTi camera delivers the quality and reliability you need to achieve exceptional results.
