FOXTECH AYK-320 PRO VTOL
₹1,883,850.00 – ₹1,958,850.00
AYK-320 PRO VTOL is engineered for long-range inspections, mapping, and surveying, offering cutting-edge features for superior performance.
- 7 Days Return, Exchange & Refund Policy.
- Free Delivery within 3 to 5 Days.
- Assured Product Quality. We deal with only Genuine Products.
- Peace of mind Warranty. Check Our Warranty Policy.
- Contact Us for Any Assistance.
Guaranteed Safe Checkout
Latest DLVR Airspeed Measurement System
Equipped with the advanced DLVR airspeed sensor, ensuring high-precision airspeed measurements for optimal flight control.
ESC Telemetry for Enhanced Flight Stability
Provides real-time monitoring of motor and ESC status, including ESC temperature, motor voltage, current, and RPM, ensuring safe and stable flights. Notch filtering technology eliminates shakes and noise, enhancing PID tuning performance.
Dual GPS Differential Design
Boosts positioning accuracy, anti-interference capabilities, and flight stability without the need for compass calibration.
VTOL/Fixed-Wing Carbon Fiber Propellers
Designed for superior dynamic balance, reducing resonance and vibration for a smoother flight experience.
Advanced Aerodynamic Design
The VTOL arm’s curved shape minimizes flight resistance, while the upturned tail wing reduces induced drag from the airflow. The streamlined fuselage and T-tail ensure excellent climb and descent angles for versatile operation.
Specification:
Max. take-off weight: 24kg
Operating weight: 21.5kg
Basic Empty Weight: 11.5kg
Stall speed: 17m/s
Cruising speed: 21m/s
Max cruising speed: 30m/s
Max climb angle: 15°
Max climb speed: 5.6m/s
Max descent angle: 25°
Max descent speed: 9.6m/s
Option:
2x Diamond 12S 27000mAh HV
Your Purchase Includes:
RTF Combo:
1x AYK-320 PRO VTOL
1x High Efficiency Tail Motor
1x Tail ESC
1x 20 inch Propeller for Tail Motor
5x Servo
4x Motor for VTOL Mode
4x ESC for VTOL Mode
2x (pairs) 24 inch Propellers for VTOL Mode
1x Pixhawk Cube Orange Standard Set
2x AEROFOX CAN F9P Positioning Module
1x DLVR Airspeed Sensor
1x AeroFox-PMU with Hall Sensor
1x DA16S+ Radio Controller
1x Carrying Case
1x Assembling, tuned and Flying Test Service
| VTOL Version |
Pixhawk Cube Orange RTF ,X7+ Pro RTF |
|---|
