SIYI MK15 Smart Controller

60,000.00 Incl. GST. Claimable with B2B Billing.

  • Model: MK15
  • Max Transmission Range: 15 kilometers (unobstructed, free of interference)
  • Agriculture Control Range: 3.5 kilometers (flying at 3-meter altitude)
  • Channels: 13 physical channels, 16 communication channels
  • Compatible Agriculture Flight Controllers:
    – BOYING Paladin V2
    – JIYI K++ V2 / K3A Pro
    – VK V7AG
    – Pixhawk / APM based flight controllers
  • Compatible Enterprise Flight Controllers:
    – JIYI KX

Guaranteed Safe Checkout

Description

In the rapidly evolving world of precision agriculture, the SIYI MK15 Mini stands out as a versatile, high-performance drone designed to revolutionize agricultural drone operations. With its exceptional range, advanced features, and compatibility with industry-leading flight controllers, the MK15 Mini is the perfect choice for both professional and enterprise-level agricultural operations. Whether you're managing large farm areas or performing detailed crop analysis, the SIYI MK15 Mini provides the technology and tools you need for smarter farming.

Key Features and Specifications of the SIYI MK15 Mini

The SIYI MK15 Mini is equipped with a wide range of cutting-edge features to make your agricultural tasks more efficient and accurate. Here’s an overview of the technical specifications that make the MK15 Mini a standout in agricultural drone technology:

Overall Specifications:

  • Model: MK15
  • Max Transmission Range: 15 kilometers (unobstructed, free of interference)
  • Agriculture Control Range: 3.5 kilometers (flying at 3-meter altitude)
  • Channels: 13 physical channels, 16 communication channels
  • Compatible Agriculture Flight Controllers:
    – BOYING Paladin V2
    – JIYI K++ V2 / K3A Pro
    – VK V7AG
    – Pixhawk / APM based flight controllers
  • Compatible Enterprise Flight Controllers:
    – JIYI KX
  • Compatible Pixhawk Based Flight Controllers: Yes
  • Compatible Android GCS (standard RTSP video stream):
    – QGround Control
    – JIYI IFLY / Agri-Assistant
    – BOYING Agriculture
    – VK V7 Pro
  • Compatible Windows GCS (standard RTSP video stream):
    – Mission Planner


Remote Controller:

  • Monitor: 5.5-inch High Definition and High Brightness LCD Touchscreen
  • System: Android 9.0 OS, 2GB RAM, 16GB ROM
  • Dimensions (antenna overlapped): 189 x 138 x 41 mm
  • Weight: 850 g
  • Battery Capacity & Type: 10200 mAh 7.4 V 2S Li-ion, 75.48 Wh
  • Fast Charging Protocol: PD 30W
  • Battery Life: 15 hours
  • Interface & Ports:
    – Charging: Type-C
    – Firmware Upgrade: Bottom DATA (4-Pin)
    – 4G/LTE Network: SIM Card Slot
    – External Storage: TF Card Slot
    – Tripod Connect: 1/4-inch Screw Hole
    – Video Output: Standard HDMI
    – External RTK: Top DATA (4-Pin)
    – Data Transfer: USB-A
  • Waterproof Level: IP53
  • Working Temperature: -10 to 55℃

Air Unit:

  • Signal Output: 16 channels of S.BUS, 5 channels of PWM
  • Interface & Ports:
    – SBUS: 3-Pin
    – Datalink (to FC): UART 4-Pin
    – PWM Channel 1 to 5: 6-Pin
    – Video Input: Ethernet 8-Pin
    – Firmware Upgrade: Type-C
  • Dimensions (antenna excluded): 70 x 55 x 16 mm
  • Weight (antenna excluded): 100 g
  • Antenna Gain (standard omni): 5 dBi
  • Power Input: 14.8 to 58.8 V (4S to 14S)
  • Working Temperature: -10 to 55℃




IP67 FPV Camera:

  • Camera Angle: FOV 105°
  • Dimensions: 106 x 25 x 41 mm
  • Weight: 108 g
  • Searchlight Power Consumption: 8 W
  • Luminous Flux: 1 W / 120 to 140 lm
  • LED Type: Transparent
  • LED Angle: 120°
  • Waterproof Level: IP67
  • Working Temperature: -10 to 55℃

How the SIYI MK15 Mini Enhances Agricultural Drone Operations

The SIYI MK15 Mini is tailored specifically for the demands of precision agriculture, providing farmers and agricultural professionals with the ability to monitor large areas quickly and efficiently. Here are a few ways the MK15 Mini can enhance agricultural operations:

1. Enhanced Monitoring and Control Range

The MK15 Mini offers a maximum transmission range of up to 15 kilometers in clear conditions, allowing users to cover vast farming areas without losing connection. Its agriculture control range of 3.5 kilometers at a 3-meter altitude provides a practical balance between distance and operational efficiency. This makes it ideal for large-scale agricultural tasks such as crop spraying, field mapping, and monitoring.

2. Versatile Flight Controller Compatibility

The MK15 Mini is compatible with a wide range of flight controllers, including popular systems like BOYING Paladin V2, JIYI K++ V2, and Pixhawk-based controllers. This flexibility ensures that farmers can integrate the MK15 Mini with their existing drone systems without the need for extensive setup changes, making it a versatile addition to any agricultural fleet.

3. Real-Time Video Stream and Data Transfer

The MK15 Mini’s ability to stream high-definition video via standard RTSP video streams on Android and Windows-based GCS (Ground Control Station) applications such as QGround Control and Mission Planner provides real-time insights into crop conditions, pest infestations, and other key parameters. This makes it easier to make informed decisions while in the field.

4. All-Weather Durability

Equipped with an IP67-rated FPV camera, the MK15 Mini can operate in challenging weather conditions, whether it’s rain, fog, or dust. This level of waterproofing ensures that your drone remains operational even in less-than-ideal conditions, providing consistent performance across seasons.

5. Long Battery Life for Extended Operations

With a 15-hour battery life, the MK15 Mini ensures long-duration flights for extended agricultural tasks, such as field mapping or crop inspection. Its PD 30W fast charging feature ensures quick recharging times, minimizing downtime between flights.

Most Searched Questions About the SIYI MK15 Mini

1. What is the maximum transmission range of the SIYI MK15 Mini?

The SIYI MK15 Mini has a maximum transmission range of 15 kilometers in clear, unobstructed conditions.

2. How far can the SIYI MK15 Mini control agricultural operations?

The MK15 Mini can control agricultural operations at a range of up to 3.5 kilometers when flying at a 3-meter altitude.

3. What flight controllers are compatible with the SIYI MK15 Mini?

The MK15 Mini is compatible with BOYING Paladin V2, JIYI K++ V2, Pixhawk-based flight controllers, and more.

4. How long can the SIYI MK15 Mini fly on a single charge?

The MK15 Mini provides up to 15 hours of flight time on a full charge.

5. What type of camera does the SIYI MK15 Mini use?

The SIYI MK15 Mini is equipped with an IP67-rated FPV camera with a 105° field of view.

6. Is the SIYI MK15 Mini waterproof?

Yes, the SIYI MK15 Mini is rated IP53 for the remote controller and IP67 for the FPV camera, ensuring it can withstand various weather conditions.

Why Choose the SIYI MK15 Mini for Agricultural Drone Operations?

The SIYI MK15 Mini is a powerful and reliable tool designed to elevate agricultural drone operations to the next level. With its long transmission range, advanced compatibility with popular flight controllers, rugged design, and extended battery life, it provides all the features needed for precision farming, crop monitoring, and field mapping.

Get your SIYI MK15 Mini today from MavDrones, the leading drone retailer in India, and experience the next generation of agricultural drone technology. Whether you're a seasoned professional or just starting out in the field of agricultural drone operations, the SIYI MK15 Mini will transform the way you work, helping you to increase efficiency, reduce costs, and improve crop yields. MavDrones offers expert customer service, fast delivery, and competitive pricing, making it the go-to destination for all your drone and accessory needs!
